Features
? Low pressure drops and high flow rates
? High filtration efficiency, up to 96%
? Excellent chemical compatibility
? High dirt holding capacity and long service life
Applications
? Food & Beverage
? Chemicals & Oil
? Pharmaceutical
? Process Water Treatment
? Pre-filtration of vent & gas
Dimension
?Diameter 69 mm
?Length 5”, 10”, 20”, 30”, 40”
Food Contact Compliance
? Materials of construction comply with FDA regulations for food and beverage contact use as detailed in the US Code of Federal Regulations 21CFR
? Materials used to produce filter media and hardware meet the specifications for biological safety per USP Class VI-121 °C for plastics
? Filter cartridges passed European Commission Directives (EU10/2011)
? Halal Certified
Material of Constructions
? Media GF
? Support PP
? Core/Cage/End Cap PP
? Seal Material Silicone, EPDM, NBR, FKM, E-FKM
Performance
? Operating Conditions
? Max. Operating Temperature 80 °C
? Max. Operating DP 4.0 Bar @ 20 °C
? 2.4 Bar @ 80 °C
